RAM® Large Strap Hose Clamp Mount for Beechcraft Bonanza Airplanes
RAM® Large Strap Hose Clamp Mount for Beechcraft Bonanza Airplanes
RAM® Large Strap Hose Clamp Mount for Beechcraft Bonanza Airplanes
RAM® Large Strap Hose Clamp Mount for Beechcraft Bonanza Airplanes

RAM® Large Strap Hose Clamp Mount for Beechcraft Bonanza Airplanes

Size
Availability and ShippingQuantity
Sizeuniwersalny
Product made to order
Product made to order
List price89,74 €
93,37 €
/ pc incl. VAT
14 days for easy returns
This product is not available in a stationary store
Safe shopping
  • View details
  • Recommended products
  • Ask a question
  • Opinions
  • View details
    The RAM-B-108B-STRAP40 accommodates rails from 2" to a maximum of 3" in diameter. To mount the RAM-B-108B-STRAP40 base, place the saddle shaped plate on the rail then wrap the metal clamp strap around the rail and plate. Tighten the screw knob on the metal strap with a screwdriver until the strap has a firm hold on the rail. The RAM-B-108B-STRAP40 is an alternative mounting base for aircraft such as the Bonanza or Beech with a throw over yoke.
    Symbol
    RAM-B-108-STRAP40
    Producer code
    793442937552
    Product Weight
    376 g
    Hardware Included
    (1) #40 Worm Drive Strap Clamp|(1) 6" Rubber Strip
    Clamp Range
    2" - 3" diameter
    Socket-to-Socket Length
    3"
    Hole Pattern
    4-Hole AMPS: 1.181" x 1.496"|3-Hole 120-Degree: 1.812" Diameter
    AMPS 4-Hole
    3-Hole 120 Degree (Small)
    Weight Capacity
    Standard Use: 907.18 gramss|Heavy-Duty Use: 453.59 grams
    Materials
    Marine-grade aluminum
    Packaging Type
    Retail Bag
    Mounting Type
    Handlebar/Rail
    Ball & Socket Size
    B Size 1" (Holds 907.18 gramss)
    Socket Arm Length
    Medium Arm
    Diameter Range
    1" - 2.1"
    Vehicle Type
    ATV
    UTV
    Aircraft
    Component parts
    RAM-B-108B-STRAP40U
    RAM-B-201U
    RAM-B-202U
    Socket To Socket Length
    3"
    Ball Size
    B Size (1")
