RAM® Powered Dock for Tab Active5 & 3 with Speaker Box
Part#:UPC:
RAM-HOL-SAM61PU
793442014352
- Features:
- RAM® EZ-Roll'r™ Powered form-fit dock provides charging capabilities for the Samsung Galaxy Tab Active3 and Tab Active2 through integrated pogo pin connector and built-in hardwire charger.
- Integrated dual speakers on the bottom of the dock for amplified audio
- Access to speakers, mics, NFC reader and headphone jack remain while device is docked
- Compatible with B and C size RAM® 4-hole AMPS pattern bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
- Backed by a 3-year warranty
- RAM® EZ-Roll'r™ Powered form-fit dock provides charging capabilities for the Samsung Galaxy Tab Active5, Tab Active3 and 2 through integrated pogo pin connector and built-in hardwire charger.
- Compatible with RAM® 4-hole AMPS pattern bases for attaching a double socket arm; ball and socket technology allows for near-infinite adjustability
Brand
Symbol
RAM-HOL-SAM61PU
Producer code
793442014352
Series
Product Weight
440 g
544 g
Hardware Included
(4) #8-32 x 5/8" Machine Screws|(4) #8-32 Nylock Nuts|(2) Small Cable Ties
Speaker Specifications
Max volume level: 103dB @ 100mm
Hole Pattern
4-Hole AMPS: 1.181" x 1.496"
AMPS 4-Hole
Materials
High strength composite
Packaging Type
Poly Bag
Input Voltage
10-28V DC
10-28VDC
Input Connector
Hardwire Charger with SAE Connector
Input Cable Length
1.9 Meters
Compliance
SAE J-1113, Integrated Short Circuit Protection
Certifications
FCC, CE, RoHS, WEEE, E-Mark
Device or Accessory Type
Tablet
Regulatory
SAE J-1113, Integrated Short Circuit Protection
Samsung Tab Active2
Samsung Tab Active3
Samsung Tab Active5
Ask a question
Write your opinion
- View details
This powered dock for the Samsung Tab Active5, Tab Active3 and 2 retains all the same capabilities as the other RAM EZ-Roll'r powered docks for the Tab Active5/3/2, with an added dual speaker integrated into the bottom of the dock for amplified audio while on the road. Power capabilities are provided to the device through pogo pins, and you can easily rotate the device for use in portrait or landscape mode. Additional cavity in the back of the dock allows room for the GDS Hand-Stand and shoulder strap accessories. Access to the stylus remains while the device is docked. Included is a set of four nuts and bolts to connect the dock to any RAM components containing the universal AMPS hole pattern. BrandSymbolRAM-HOL-SAM61PUProducer code793442014352SeriesProduct Weight440 g544 gHardware Included(4) #8-32 x 5/8" Machine Screws|(4) #8-32 Nylock Nuts|(2) Small Cable TiesSpeaker SpecificationsMax volume level: 103dB @ 100mmHole Pattern4-Hole AMPS: 1.181" x 1.496"AMPS 4-HoleMaterialsHigh strength compositePackaging TypePoly BagInput Voltage10-28V DC10-28VDCInput ConnectorHardwire Charger with SAE ConnectorInput Cable Length1.9 MetersComplianceSAE J-1113, Integrated Short Circuit ProtectionCertificationsFCC, CE, RoHS, WEEE, E-MarkDevice or Accessory TypeTabletRegulatorySAE J-1113, Integrated Short Circuit Protection - CompatibilitySamsung Tab Active2Samsung Tab Active3Samsung Tab Active5
